적층 제조에서는 신속한 프로토타이핑이 가장 중요합니다.

“Our manager reviewed new technologies that would ensure we kept pace with change and serving our customers’ needs,” Maier said. “He quickly saw an advantage in additive manufacturing. Considering our requirements for larger build-tray size as well as high- quality, precise part production, we found the Stratasys Fortus 450mc an ideal fit for us.”

The ability to 3D print highly complex, customized fixtures for laser devices and engraving machines has had a considerable positive impact on in-house production and timing.



“We traditionally produced our fixtures on our milling machines, which took up a lot of time and held up production throughput,” Maier said. “Since the installation of our new Stratasys 3D printer, we can have the fixture ready the next day, which results in a 90% time savings.”



The efficiencies of additive manufacturing means Kratzer no longer has to create design drawings for fixtures, skipping several time-consuming production steps. Fixtures can now be printed in one operation, instead of producing multiple parts and then assembling them after milling.



Customizing fixtures for specific parts with the Fortus 450mc is especially important to the company’s business because of the increased flexibility.



“Often our customers want a serial number, logo or writing on their parts, which is done by our laser engraving machines,” Maier said. “Before 3D printing, we had to put each part separately into the laser device, or manufacture custom fixtures to hold several parts. With additive manufacturing, we can create fixtures to laser 30 parts simultaneously, saving us an incredible amount of time and labor.”

With the Fortus 450mc, Kratzer is able to produce durable fixtures with complex geometries without compromising quality. While printing most parts out of polycarbonate and ABS, ULTEMTM resin material has also proved to be invaluable for certain production requirements, particularly fixtures that must withstand extreme temperatures or resist chemical solutions.



“Making adaptations to parts is easy with additive manufacturing, and the material we use for our fixtures ensures they are fit for purpose,” Maier said. “We have traditionally manufactured fixtures, which over time naturally start to crack and break. Previously, we had to wait for the team to manufacture another fixture, which delayed the production process by several days. Now, we have the file, we can 3D print it in just a few hours. This dramatically enhances our production flow.”



In addition to making the production line workflow more efficient, additive manufacturing has elevated the level of in-house training. According to Maier, employees are much more excited and motivated about constructing and working with fixture designs. For Maier, personally, the Fortus 450mc has had an even more profound impact. “This technology has enabled a fundamental new way of additive thinking across the design process for fixtures,” Maier said.
